CustomizableItems
Cutting DlA. Custom : design various cutting diameter based on demand, such us Φ950、 Φ1o50 etc;
Shell HIT. Custom : design as demand, prolong or shortten, increase amount of per drilling, improve efficiency;
Bottom Custom : single bottom and double bottom design as demand;
Kelly Box Custom : custom kelly box size based on the kelly bar, such us 130*130, 150*150,200*200 etc;
Bottom Open Mechanic : half-automatic or manul mechanic bottom open system.
| 钻具直径 | 筒体高度 | 筒壁厚度 | 固定底厚度 | 重量 |
| Diammeter | Shell Height | Shell Thk | Bottom Plate Thk | Weight |
| 600 | 900 | 16 | 40/50 | |
| 700 | 900 | 16 | 40/50 | |
| 800 | 900 | 16 | 40/50 | |
| 900 | 900 | 16 | 40/50 | |
| 1000 | 900 | 16 | 40/50 | |
| 1200 | 900 | 20 | 40/50 | |
| 1250 | 800 | 20 | 40/50 | |
| 1300 | 800 | 20 | 40/50 | |
| 1400 | 800 | 20 | 40/50 | |
| 1500 | 800 | 20 | 40/50 | |
| 1600 | 800 | 20 | 50/50 | |
| 1800 | 800 | 20 | 50/50 | |
| 2000 | 800 | 20 | 50/50 | |
| 2200 | 600 | 20 | 50/50 | |
| 2500 | 600 | 20 | 50/50 | |
| 3000 | 600 | 20 | 50/50 | |
| 可选方头 | 三一150方 | 宝峨200方 | 宝峨250方 | |
| Kelly Box | 150*150 | 200*200 | 250*250 | |
| 钻底样式 | 双底双开门 | |||
| Bottom Type | Double Bottom Double Cut | |||
| 备注：度量单位为mm，重量单位为kg。数据仅供参考，可根据施工地质确认钻斗选型。 The unit of measurement is millmeters and the weight is kilograms. The data are for reference only. The drill bucket type can be confirmed according to the site layer condition. |
||||
