CustomizableItems
Cutting DIA. Custom : design various cutting diameter based on demand, Isuch us o950, o1050 etc.
Teeth Custom: equiped different teeth, like bullet teeth, flat teeth according to different working condition
Kelly Box Custom : custom kelly box size based on the kelly bar, such us 130*130, 150*150,200*200 etc
| 钻具直径 | 筒体高度 | 筒壁厚度 | 齿板厚度 | 齿数 | 重量 |
| Diammeter | Shell Height | Shell Thk | Teeth Plate Thk | Teeth Number | Weight |
| 600 | 1200 | 30/30 | 50 | 8 | 910 |
| 700 | 1200 | 30/30 | 50 | 9 | 1010 |
| 800 | 1200 | 30/40 | 50 | 10 | 1265 |
| 900 | 1200 | 30/40 | 50 | 12 | 1380 |
| 1000 | 1200 | 30/40 | 50 | 14 | 1560 |
| 1200 | 1200 | 30/40 | 50 | 18 | 2310 |
| 1500 | 1200 | 30/40 | 50 | 22 | 3400 |
| 可选方头 | 三一150方 | 宝峨200方 | 宝峨250方 | ||
| Kelly Box | 150*150 | 200*200 | 250*250 | ||
| 钻底样式 | 土层体开（配宝峨FZ80 齿或V20 齿） | 嵌岩体开（配嵌岩截齿） | |||
| Bottom Type | Open-type Soil Bucket （Bauer Teeth FZ80 or V 20） | Open-type Rock Bucket (Bullet Teeth) | |||
| 备注：度量单位为mm，重量单位为kg。数据仅供参考，可根据施工地质确认钻斗选型。 | |||||
| The unit of measurement is millmeters and the weight is kilograms. The data are for reference only. | |||||
| The drill bucket type can be confirmed according to the site layer condition. | |||||
